# Beautiful Math with LaTeX

Beautiful Math with LaTeX

LaTeX is a powerful markup language for writing complex mathematical equations, formulas, and more. Jetpack combines the power of LaTeX and the simplicity of WordPress to give you the ultimate in math blogging platforms.

To enable this module, visit Jetpack → Settings → Writing in your site’s dashboard. Scroll down to the Composing section and toggle on the Use the LaTeX markup language to write mathematical equations and formulas option.

Using LaTeX
To include \LaTeX code in your post, use the following:

$your-latex-code-here$

So, for example,

$i\hbar\frac{\partial}{\partial t}\left|\Psi(t)\right>=H\left|\Psi(t)\right>$

produces

i\hbar\frac{\partial}{\partial t}\left|\Psi(t)\right>=H\left|\Psi(t)\right>

LaTeX Error
If your \LaTeX code is broken, instead of the equation you’ll see an ugly yellow and red error message. Sorry, we can’t provide support for \LaTeX syntax, but there are plenty of useful guides elsewhere online. Or a quick post in our forums might find you a solution. One thing to keep in mind is that WordPress puts all of your \LaTeX code inside a \LaTeX math environment. If you try to use \LaTeX that doesn’t work inside the math environment (such as \begin{align} … \end{align}), you will get an error:

\LaTeX&s=X

LaTeX Size
You can change the size of the LaTeX by specifying an s parameter after the \LaTeX code.

$\LaTeX&s=X$

Where X goes from -4 to 4 (0 is the default). These sizes correspond to \LaTeX‘s font size commands:

s= font size Example
-4 \tiny \LaTeX
-3 \scriptsize \LaTeX
-2 \footnotesize \LaTeX
-1 \small \LaTeX
0 \normalsize (12pt) \LaTeX
1 \large \LaTeX
2 \Large \LaTeX
3 \LARGE \LaTeX
4 \huge \LaTeX
LaTeX Colors
WordPress tries to guess the background and foreground colors of your site and generates the \LaTeX image accordingly. But, you can change the colors. You can specify bg and fg parameters after the \LaTeX code to change the background and foreground colors, respectively. The colors must be in hexadecimal RGB format: ffffff for white, 0000ff for bright blue, etc.

$\LaTeX$

\LaTeX

LaTeX Packages
WordPress.com uses standard \LaTeX with the following packages:

amsmath
amsfonts
amssymb
For more information about \LaTeX, you can visit LaTeX documentation site and TeX Resources by American Mathematical Society.

Privacy Information
This feature is activated by default. While there are no controls for it within the primary Jetpack settings area, it can be deactivated any time by following this guide.

Data Used
Site Owners / Users
None.

Site Visitors
None.

Activity Tracked
Site Owners / Users
None.

Site Visitors
None.

Site Owners / Users
We sync a single option that identifies whether or not the feature is activated.

Site Visitors
None.
